NEW Cablecross CC25HD & CC66HD

LITEC proposes the new Cablecross line to meet the increasing need of a safe way of laying and protecting cables, hoses and ducts in public areas, offices, trade and exhibition centres, live events. It consists of two models, CC25HD and CC66HD with their corners. They are patented and superior quality products.

Main technical specifications
Reaction to Fire: CLASS 1 in accordance with the uni 9174 + uni 8457
Complies with the EEC 73/23 directives regarding the low voltage electrical equipment
Can be crossed by heavy vehicles according to its maximum roll-on load: 170N/cm2
Excellent resistance to solvents, acids, oils and atmospheric agents
Max. operating voltage: 1000v c.a. - 1500 v c.c.
Insulation resistance: 29.5 GΩ
Protection: IP30xc (according to CEI EN 60529-9/92 regulations)
Surface hardness: 90-98 (shore A).

CC25HD – 3-channel cable duct
Dimensions: 250x34x1000mm
Weight: 3.25 kg

CC66HD – 3-channel cable duct
Dimensions: 662x73x1000mm
Weight: 14.3 kg
