QX30SA

Square section aluminium truss twist-resistant version with 29 cm long sides.
  • Chords A: extruded tube Ø 50 x 2 mm EN AW 6082 T6
  • Diagonals B: extruded tube Ø 18 x 2 mm EN AW 6082 T6
  • Ends C: aluminium casting plate EN AC 42200 T6
  • Connection systems QXFC: quick-fit kit; QXSM10: bolt connection kit

It substitutes the model QX30S, from which it keeps the excellent size, weight, cost and performance characteristics. It is made of 6082 alloy extruded components, with high load-bearing and twisting strength. It is a constitutive element of Unitower, Towerlift 3, and Flyintowers 6-300 and 7.5-500.
